Quick Details

  • Condition: New
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: AULIFT or customerized brand
  • Model Number: AL-800, AL-1600,AL-3200
  • Usage: for pulling
  • Power Source: Lever
  • Sling Type: Wire Rope
  • Maximum Lifting Weight: 5400kgs
  • Warranty: 1 year
  • color: blue painted or grey painted or orange painted
  • capacity: 800kg,1600kg,3200kg

Packaging & Delivery

Packaging Details: each peice be packed in poly bag and carton, 10pcs of pulling hoist body and 10pcs of lever and 10rolls of steel wire rope be packed in one strong ply-wood carton.
Delivery Detail: 20-25 days after buyer confirming order

Specifications

1. We have both alu.body and steel body
2. capacity: 800kg,1600kg,3200kg,5400kg
3. surface finishing: color painted
4. CE,GS

1. Wire rope pulling hoist (cable pller)Wire rope pulling hoist also named wire rope pulling winches,wire rope pulling machines,manual wire rope pulling tools and so on.

Wire rope pulling hoist have three kinds of capacity:800kg,1600kg.3200. Normally it has 20 meters wire rope.

Finer wire rope pulling machines is Aluminium material which means long working life.

Wire rope pulling winches is an extremely tools for pulling,lifting and securing goods.which is easy and safe to operate.

Via wire rope pulling hoist is easy to move objects several tons in weight by one person.

This winches has lower maintenance requirements,to save your cost.




800 KG wire rope pulling hoist specifications:

Model: AL-800

Rated Capacity(KG): 800 kg

Rated Capacity(LBS): 1762 LBS

Rope Advance Per Full Stroke:55mm

Wire Rope DIA (Ø in mm) :8.3 mm

Wire Rope Safety Factor:5.0 times

Static Load Safety Factor:4.0times

Max.Dynamic Load:1250kg

N.W without Rope:6.0kg

Wire Rope Standard Length:20 meters.

Package Size:428*64*325mm




1600 KG wire rope pulling hoist specifications:

Model: AL-1600

Rated Capacity(KG): 1600 kg

Rated Capacity(LBS): 3524 LBS

Rope Advance Per Full Stroke:55mm

Wire Rope DIA (Ø in mm) :11.0 mm

Wire Rope Safety Factor:5.0 times

Static Load Safety Factor:4.0times

Max.Dynamic Load:2000kg

N.W without Rope:11.0kg

Wire Rope Standard Length:20 meters.

Package Size:545*97*286mm





3200 KG wire rope pulling hoist specifications:

Model: AL-3200

Rated Capacity(KG): 3200 kg

Rated Capacity(LBS): 7050LBS

Rope Advance Per Full Stroke:40mm

Wire Rope DIA (Ø in mm) :16.0mm

Wire Rope Safety Factor:5.0 times

Static Load Safety Factor:4.0times

Max.Dynamic Load:4000kg

N.W without Rope:22.0kg

Wire Rope Standard Length:20 meters.

Package Size:660*116*350mm



We have both au.boy and steel body pulling hoist(cable puller) availalbe.




Strong packing for pulling hoist--wire rope winch- cable puller
